1) Genelec позиционируют 7040 в пару к 8010:
"The combination of the 8010 and our 7040 subwoofer provides a compact professional setup with a controlled and extended frequency response, allowing you to hear everything you need to create high-quality mixes."
2) Рекомендации по настройке 8010 и 7040:
"Setting the Input Sensitivity
The 7040A has the same sensitivity as 8010, 8020 and M030 monitors in free field. However, when placed near reflect-ing surfaces the sensitivity of 7040A typi-cally must be attenuated due to increased wall loading. A typical initial setting for the rotary sensitivity control is -4 dBu.
The +12 dBu setting provides maximum attenuation The use of proper measuring equipment with careful listening is highly recommended.
3) 7050 предполагается производителем в следующих сетапах:
"7050C
2 channel system: 8020, 8030, M030
5 channel system: 8010, 8020
Room volume up to 75 m3 / 2647 ft3"
4)7040 частота кроссовера 85 Hz (хотя в каталоге 2023 года указано 90 Hz - "Free field frequency response 30 Hz - 90 Hz (-6 dB)")
"The bass management unit in the 7040A subwoofer splits the input into low and high frequency components at 85 Hz. Frequencies below 85 Hz are reproduced by the subwoofer. Frequencies above 85 Hz are directed via the subwoofer's output connectors to the main monitors. The subwoofer's outputs have the same level as the inputs."
5)7050 частота кроссовера тоже 85 Hz, а 120 Hz только через вход LFE:
"The bass management section of the 7050C features five input and output channels with 85 Hz low-pass/high-pass filters, plus a discrete 120 Hz LFE signal input with selectable +10 dB boost to restore the normal level of the LFE channel in the way that a typical AV processor would. "
+
"With five input and output channels with 85 Hz filtering - plus a 120 Hz LFE input - the 7050C is equally suited to stereo or multichannel work, and its laminar spiral enclosure provides extended LF response down to 24 Hz with impressively low distortion. Rear panel DIP switches control subwoofer phase and LF roll-off, engage the +10 dB LFE level, and also activate and control the sensitivity of the 7050C’s ISS power-saving mode."
