Phase 22 Synthesis Engine
Phase 22 Synthesis Engine
- 2 Oscillators (sine wave, phase modulation, frequency randomization)
- 2 Shapers (sine curve, adjustable foldback and asymmetry)
- Ring Modulator
- Comb Filter (tunable, with allpass and lowpass)
- State Variable Filter (multi-mode, 2-4 poles, FM)
- Feedback Mixer (4 input signals, shaper for the sum)
- Feedback bus with 4 destinations
- Output Mixer (stereo, 4 input signals, shaper for the sum)
- 5 Stereo Effects: Cabinet (amp simulation), 8-pole Gap/Band Filter, Flanger/Chorus, Echo, Reverb
- 3 ADBDSR Envelopes, adjustable attack curve
- Velocity sensitivities for envelope levels, attack times, and release times
- 4 Macro Controls, assignable to up to 86 target parameters
- 8 Hardware Sources, mappable to the 4 Macro Controls
- Number of parameters: 305
- Resolution of the parameters: typically 1000 steps (250 ... 15000 steps)
- Resolution of key velocity, ribbons, lever, aftertouch, pedals: 4000 steps
- 12-voice polyphony, variable Unison settings
